UV Lenses and Lens Design for electronics, optics, medical and precision industrial applications.

UV0635BCM-Ultraviolet Quartz Lens Assemblies

Our line of Ultraviolet Lenses is designed for imaging in the deep UV spectrum

UV lenses optimized for 250nm wavelength.

Available from stock in 6, 9, 12, 16, 25, 35, 50, 60, 78, and 105mm focal lengths, these lenses are well suited to forensic investigation and other UV and Infra-red imaging applications.

We have designed and manufactured these lenses as a reasonably priced solution to the growing need for imaging in the other than visible spectrum. Owing to the broad transmission range of the elements this family of lenses can transmit well into the Infra-red spectrum as well.

The typical transmission of the Universe family of lenses is optimized for 250nm, however, there is a wide range of transmission. Be advised that the lenses are NOT corrected for constant focus throughout their range. Re-focus will be required at different wavelengths.

Applications Include: – Electronics, Optics, Medical and Precision Industrial applications.

We offer a full line of camera specific T- mount adapters and filters to fit all of our lenses. We also have bare filter rings to mount your custom filters if desired, for maximum versatility. Please call 516-624-2444 to learn more about this useful offering of lenses.

View Products: Ultraviolet Lens Assemblies

Click on a Part Number to view product details and an outline drawing.

Part NumberFocal LengthF/No.Sensor SizeMountIris ControlLens ApplicationDimensions (diameter x length)
UV0635BCM6.0mm3.5 - 161/1.8"C-MountAdjustableUltraviolet34.0mm x 32.5mm
UV0928CM29.0mm2.8 - 161/1.8"C-MountAdjustableUltraviolet29.0mm x 31.8mm
UV1228CM12.0mm2.8 - 162/3"C-MountAdjustableUltraviolet29.0mm x 31.1mm
UV1628CM16mm2.8 - 161/1.2"Ultraviolet29.0mm x 36.7mm
UV252825.0mm2.81"C-MountFixedUltraviolet30.0mm x 25.7mm
UV2528B25.0mm2.8 - 161"C-MountAdjustableUltraviolet30.0mm x 28.9mm
UV3528B35.0mm2.8 - 1622.0mmC-MountAdjustableUltraviolet57.5mm x 57.9mm
UV3528MFT35.0mm2.8 - 1622.0mmMicro Four Thirds MountAdjustableUltraviolet57.5mm x 56.3mm
UV5035B50.0mm3.5 - 1643.3mmT with Removable C-Mount AdapterAdjustableUltraviolet61.0mm x 95.1mm
UV6035B60.34mm3.5 - 1643.3mmT with Removable C-Mount AdapterAdjustableUltraviolet61.0mm x 98.6mm
UV8040BK278.0mm3.8 - 1643.3mmT with Removable C-Mount AdapterAdjustableUltraviolet62.5mm x 109.3mm
UV1054B105.0mm4.0 - 2243.3mmT with Removable C-Mount AdapterAdjustableUltraviolet62.5mm x 123.1mm
UVS06286.0mm2.81/1.8"M12 S-MountFixedUltraviolet18.5mm x 23.35mm
UVS09289.0mm2.81/1.8"M12 S-MountFixedUltraviolet16.0mm x 17.0mm
UVS122812.0mm2.81/1.8"M12 S-MountFixedUltraviolet16.0mm x 20.0mm
UVS162816.0mm2.81/1.8"M12 S-MountFixedUltraviolet16.0mm x 20.0mm
UVS2528

25.0mm2.82/3"M12 S-MountFixedUltraviolet16.0mm x 20.0mm
